DJI Goggles 2

Product detailed description

DJI Goggles 2 provide next-level comfort and convenience in FPV. Now smaller, lighter and equipped with Micro-OLED screens. DJI Goggles 2 are compact and ultra-portable. The foldable antenna and lightweight design make them easy to store, comfortable to wear and suitable for long-term use. With two hours of battery life and super fast charging, you can always be ready for flight.

• Compact and portable design 290 g

• Two 1080p Micro-OLED screens

• Diopter correction from +2.0 to -8.0 D

• 1080p/100fps video transmission with 30ms latency

• Wireless Wi-Fi streaming with DLNA support

Description:

• Supported video and audio playback formats: MP4 and MOV (video encoding formats: H.264 and H.265; audio format: ACC, PCM)

• Wi-Fi transmission power (EIRP)


2.4 GHz: < 20 dBm (FCC/CE/SRRC/KC)
5.1 GHz [8]: < 20 dBm (FCC/CE/KC)
5.8 GHz [4]: < 20 dBm (FCC/SRRC/KC), < 14 dBm (CE)

• Transmission power (EIRP):


2.4 GHz: < 30 dBm (FCC), < 20 dBm (CE/SRRC/KC)
5.8 GHz: < 30 dBm (FCC), < 23 dBm (SRRC), < 14 dBm (CE/KC)

• Operating temperature range: -10° to 40° C (14° to 104° F)

• Bluetooth communication frequency: 2.400-2.4835 GHz

• Wi-Fi Wireless Streaming: Supports DLNA protocol

• Bluetooth transmission power (EIRP): < 8 dBm

• Supported SD cards: microSD (up to 256 GB)

• Maximum video bit rate: 50 Mbps

• Wi-Fi Communication Frequency:


2.400-2.4835 GHz / 5.150-5.250 GHz (indoor use only) 5.725-5.850 GHz

• Wi-Fi protocol: Wi-Fi 802.11b/a/g/n/a

• Power: DJI Goggles 2 battery

• Bluetooth protocol: Bluetooth 5.2

• Video Recording Format: MOV

• Communication Frequency


2.400-2.4835 GHz / 5.725-5.850 GHz

• FOV (single screen): 51


DJI Goggles 2 battery

• Charging Temperature Range: 70° to 45° C (32° to 113° F)

• Maximum charging power: 712.6 W (5 V/2 A, 9 V/1.4 A)

• Dimensions (L×W×H): 73.04×40.96×26 mm

• Operating Time: Approx. 2 hours

• Chemical system LiNiMnCoO2

• Weight: Approx. 122 g

• Voltage: 7-9 V (1.5 A)

• Capacity: 1800 mAh

• Energy: 18 Wh

• Type: Li-ion

Package Contents:

• 1x DJI Goggles 2 Dual Band Antenna (Set of 2)

• 1x DJI Goggles 2 goggle frames (set of 2)

• 1x DJI Goggles 2 protective film (set of two)

• 1x DJI Goggles 2 power cable

• 1x DJI Goggles 2 head strap

• 1x DJI Goggles 2 battery

• 1x DJI Goggles 2

• 1x OTG cable
